Cross Road / Gravel Rim DT Swiss E 550 700c 30 mm DB VI

The sturdy aero rims for all-road use.

Would you like to customise your road bike to save energy on long distances? Then our aerodynamically optimised E 550 rim is exactly what you’re looking for. The E 550 is designed for long distances and offers the right balance of stability and comfort: with a 22 mm rim width – ideal for 28 mm wide tyres – it improves the riding experience at low tyre pressure and reduces rolling resistance. This ensures maximum riding pleasure kilometre after kilometre.

DT Swiss E 550 DB Rim Technology:

• Application: Endurance, Cross, Gravel
• Suitable for use with disc brakes only
• ETRTO 622 x 22, 28-inch, 700 C
• ERD 585 mm
• Material: Aluminium EN AW-6061 T6
• Width 26 mm, height 30 mm, rim width 22 mm
• Maximum tyre width 25–50 mm
• Valve hole 6.5 mm
• Weight 580 grams
• Max. system weight 130 kg
• ASTM classification 2

DT Swiss Sleeve Joint technology:

The stability of the rim is ensured by the Sleeve Joint process, which is the best alternative to welding. This involves inserting the rim using a moulded part that is pressed evenly into the profile. This creates a stable and highly durable joint.

DT Swiss tubeless-ready rim:

The profiles of DT Swiss tubeless-ready rims are specially designed for tubeless use. They guarantee a perfect fit and make tyre installation as easy as possible. Nevertheless, it is always possible to use a conventional combination of tyre and inner tube. DT Swiss tubeless-ready rims offer further advantages over conventional rims. Thanks to the design of their cross-section, the tyre simply pops into place when inflated, meaning that in most cases only a standard floor pump is required. The sophisticated profile of DT Swiss rims also ensures a precise and secure fit for the tyre, even under tough riding conditions.

Your custom wheel set with the DT Swiss E 550 DB rim.

Ask us for a bespoke quote. We will build your dream wheelset, perfectly hand-laced. We use exclusively DT Swiss spokes. Over the last few decades – ever since we started building wheelsets – these spokes have proven themselves to be by far the most durable.

Herstellerinformation: DT Swiss, Längfeldweg 101, 2504 Biel, Bern, Switzerland, https://www.dtswiss.com/
