Mavic Cosmic SLR 40 replacement spoke

The replacement spoke for the front wheel of the Cosmic SLR 40 Rim Brake wheelsets.

Your Mavic wheel is damaged; we repair all Mavic wheels, provided the spare parts are still available. Please send us the serial number of your wheel, stating the nature of the damage. We will then check whether a repair is possible. The serial number is located on the rim next to the barcode.

Mavic Cosmic Carbon SLR 40 Rim Brake front wheel, Part No. F9242101, Spare parts:

• Replacement front wheel rim, 18-hole, height 40 mm, width 26 mm, rim width 19 mm, Item No.:V4094710
• Replacement Aero 277 mm spokes with M6 nipples and washers, Part No: V3669501
• Hub bearing type 6901 / 12x24x6 mm Item No: M40078
• Hub axle QRM Auto 9 x 100 mm Item No.:V2375801
• Axle end stops Item No: 35117301

Mavic Cosmic Carbon SLR 40 Rim Brake rear wheel, Part No. R4013155, Spare parts:

• Replacement rear wheel rim, 24-hole, height 40 mm, width 26 mm, rim width 19 mm, Item No: V4094813
• Right-hand replacement spokes Aero 266 mm with M6 nipples, Part No: V4161601
• Left replacement spokes Aero 285 mm with M6 nipples, Item No: V3669301
• Hub bearing type 6903 / 17x28x7 mm Item No.: V2560401
• Rear wheel axle kit 130 for ID360 UB hub with retaining ring and cover Part No: V2252801
• Sprocket retainer with retaining ring Part No: V2252701
• Freewheel body seal Part No: V00063631
• Sprocket kit with spring Part No: V2251701
• Rubber for noise damping Item No.: V2500501
• Road spring for toothed discs Part No: V2251801
• Bearing cover with shaft washer and circlip Part No: V2373001
• Axle end stops, quick-release mount, Part No: V2253101

Compatible Mavic Instant Drive 360 freehub body:

• Aluminium Light freehub body for Shimano HG + Sram cassettes Item No: V3850101
• Aluminium freehub body for Shimano HG + SRAM cassettes Item No: V3430101
• Aluminium freehub body for Campagnolo ED cassettes 10-12 speed Item No: V3440101
• Aluminium freehub body for Campagnolo N3W cassettes 10-12 speed Item No: V4270101
• Aluminium freehub body for Sram XDR and XD cassettes Item No: V2580101
• Aluminium freehub body for Shimano Microspline cassettes Item No.: V3990101
