MTB rim DT Swiss FR 571

The freeride and downhill rim from DT Swiss. With a wider rim flange, the FR 571 offers even greater puncture resistance.

Included in delivery

• DT FR 571 rim, flat hex brass nipples 2.0 x 12 mm, PHR washers, decal set

DT Swiss FR 571 Disc Rim Specifications and Dimensions:

• 29-inch ETRTO: 622 x 30 mm
• ERD: 599 mm
• Hooked / Crochet tubeless TC
• Aluminium rim
• Rim joint: welded
• non-eyelet PHR
• Width: Inner 30 mm, Outer 38 mm Height 23 mm
• Maximum recommended tyre width: 2.8
• Valve hole: Presta 6.5 mm
• Recommended rim tape: 32 mm
• Weight: 695 grams
• ASTM classification 5
• Approved for e-bikes: (max. 32 km/h or 250 watts)
• Max. system weight 140 kg

Your custom wheel with the DT Swiss FR 571 rim.

Ask us for a bespoke quote. We’ll build your dream wheel, perfectly hand-trued. We use exclusively DT Swiss spokes. Over the last few decades – ever since we started building wheels – these spokes have proven themselves to be by far the most durable.

DT Swiss FR 571 DB:

Hard rock or cross-lying roots: throw yourself into the downhill adventure! The FR 571 masters every challenge and has everything it takes to conquer the Black Snake and clear gaps. The brass spoke nipples are extremely robust and suitable for the most demanding trails. Make a statement with a silver-coloured rim or stay discreetly in the background with a black rim. The FR 571 – for everyone who’s tough as nails!

Herstellerinformation: DT Swiss, Längfeldweg 101, 2504 Biel, Bern, Switzerland, https://www.dtswiss.com/
